    C9370C Disc And Drum Brake Lathe 2.85" 73mm Brake Rotor Lathe Machine

    Ask Lasest Price
    Brand Name : CAROZZA
    Model Number : C9370C
    Certification : CE
    Price : USD
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 100 pcs/Month
    Delivery Time : 10-15 days
    • Product Details
    • Company Profile

    C9370C Disc And Drum Brake Lathe 2.85" 73mm Brake Rotor Lathe Machine

    Brake Drum Disc Lathe Cutting Machine rotor lathe 2.85”(73mm)


    The feature of rotor lathe:


    1.DC motors designed to meet the demanding requirement of industrial motion control


    2.“Change Adapter" system to eliminate the need for conventional bell clamps and cones.


    3.The precision twin cutter tools and a quick drum to rotor changeover to help increase your service capability.


    4.Infinitely variable spindle and cross feed speed settings for quick rough and precision finish cuts.


    5.Positve rake cutter tip angle provides for a one pass finish virtually every time,allowing you to complete your work fast.


    Product Application-rotor lathe:


    1.The "Change Adapter" system eliminates the need for conventional bell clamps and cones and features built-in springs ensure you don't lose them.
    2.The precision twin cutter tools and a quick drum to rotor changeover to help increase your service capability.
    3. Infinitely variable spindle and cross feed speed settings allow for quick rough and precision finish cuts.
    4. A convenient top storage tray means you can easy to take that are your favorite adapters and tools.
    5. Separate motors on the drum and rotor feed help maximize the main motor's efficiency.
    6.The variety of adapters lets you machine all standard and composite rotors for foreign and domestic cars and light trucks.
    7.Positive rake cutter tip angle provides for a one pass finish virtually every time, allowing you to complete your work fast.


    The main specifications of rotor lathe:


    Spindle Travel9.875”(251mm)Spindle Speed70,88,118 RPM
    Spindle Feed Speed0.002"(0.05mm)-0.02"(0.5mm)RevCross Feed Speed0.002"(0.05mm)-0.01"(0.25mm)Rev
    Handwheel Graduations0.002"(0.05mm)Rotor Diameter7”-18”(180-457mm)
    Rotor Thickness2.85”(73mm)Drum Diameter6”-17.7”(152-450mm)
    Drum Depth9.875”(251mm)Motor110V/220V/380V 50/60Hz
    Gross Weight325KGDimension1130×1030×1150 mm
